The MXH compact pneumatic slide is a highly integrated pneumatic actuator with a variety of features and advantages, which is widely used in many fields such as automation equipment, machine tools, medical equipment and plastic machinery.
Product features
High rigidity: MXH series pneumatic slide adopts high rigidity linear guide, which improves the rigidity and stability of the slide and ensures the accurate positioning and clamping of the workpiece.
Allowable torque increase: Through design optimization, the allowable torque of MXH series pneumatic slide has been significantly increased compared to other series, up to more than 6 times that of MXU series.
Mass reduction: The new linear guide and improved piston parts have reduced the mass of the slide, such as 19% reduction in the mass of the slide at ø20-10 strokes.
Multi-directional piping: The slide supports piping from three directions (face and two sides), providing greater installation flexibility and convenience.
Buffer design: both ends of the slide table are equipped with buffer pads, which can effectively absorb the impact of the end of the stroke and protect the workpiece and fixture.
Specification parameters
Action mode: Double action.
Cylinder diameter: provide 6, 10, 16, 20 and other specifications to meet the needs of different loads and strokes.
Installation options: Support the installation of magnetic switches from three directions for easy position detection and control.
Application field
The MXH compact pneumatic slide is suitable for a wide range of applications requiring precise positioning, clamping and delivery, such as electronics and light assembly, machine building, medical equipment, etc.
Key points of selection
In the selection of MXH compact pneumatic slide, it is necessary to determine the appropriate cylinder diameter and theoretical cylinder thrust according to the actual application of load, stroke, speed and other parameters.
At the same time, it is also necessary to consider the installation space of the slide, the piping method, and whether the magnetic switch needs to be configured.
